- Resolution 720 x 720 dpi ( for paper) , 1440 x 720 dpi ( for film)
- Ink Type Epson industrial-quality, water-based, resin-coated pigment ink system ( SurePres AQ)
- Ink Colors Cyan, Magenta, Yellow, Black, Green, Orange
- Cartridge Fluids Over print, Moisture liquid
- Web Width 3.15" — 13" ( 80 — 330 mm) Adjustable to support any width in this range
- Image Size 36" x 12.4" ( 914.4 x 315.2 mm) maximum repeat lengths
Print Speed Up to 16' ( 5 m) per minute at 720 x 720 dpi ( on paper)
- Substrate Support Standard self-adhesive label stock and film ( no pre-coating required) Semi-gloss, gloss and matte paper stock, BOPP, PET and Yupo
- Substrate Thickness 0.004" - 0.013" ( 0.10 - 0.32 mm) or 100 - 320 microns ( 4 - 12.6 mil)
- Unwinder/ Rewinder Capacity ( maximum) 220 lb ( 100 kg) weight / 23.6" ( 600 mm) diameter / 3280.8 feet ( 1000 m) maximum length with 3" ( 76 mm) inner core
- Press Dimensions ( W x D x H) 12.21' x 4.76' x 6.16' ( 3722 x 1451 x 1878 mm)
- Rewinder Dimensions ( W x D x H) 4.3' x 2.95' x 3.28' ( 1310 x 900 x 1000 mm)
- Weight of Press Approximately 4078 lb ( 1850 kg) including rewinder
- Weight of Rewinder Approximately 397 lb ( 180 kg)
- Network Connectivity Ethernet 1000 Base-T or higher is recommended
- Temperature ( operating) 64° - 82° F ( 18° - 28° C)
- Relative Humidity ( operating) 35 -° 55% ( no condensation)
- Press Power Requirements Rated voltage — AC ( three-phase system) 200V
- Input voltage range — Rated ± 10% ( 180~ 220V)
- Rated frequency — 50-60Hz
- Input frequency range — Rated ± 1%
- Rated current — 30A
- Maximum Sound Level ( operating) 75dB or less ( excluding the alarm sound)
